DN100 Hydrocyclonic Magnetic Dirt Separator with Air Separator Reblotech CycloMag AirTrap – RBT-CM-004

The Reblotech CycloMag AirTrap DN100 hydrocyclonic magnetic dirt separator with air removal (code RBT-CM-004) is the ideal solution for cleaning and protecting heating and cooling systems. Designed for residential and commercial installations, it combines three essential functions in one compact unit: dirt removal, magnetic particle capture, and air separation.

Triple action operation

• Hydrocyclonic separation: removal of suspended solids
• Magnetic action: neodymium magnet N52 (1.4 T)
• Air separator: elimination of microbubbles and gases

Technical specifications

• Code: RBT-CM-004
• Connections: flanged DN100 (PN 10/16)
• Temperature: 5°C / 90°C
• Max pressure: 5 bar
• Material: carbon steel EN 10255
• Magnet: Neodymium N52 – 1.4 T
• Kv: 260

Applications

• HVAC systems
• Heating plants
• Heat pumps
